JAMMA 56 Pin Arcade Card Edge Connector Socket, PCB Mount, 3.96mm / 0.156"

(No reviews yet) Write a Review
$2.69     Buy in bulk and save

Bulk discount rates

Below are the available bulk discount rates for each individual item when you purchase a certain amount

  • Buy 10 - 29 and pay only $2.55 each
  • Buy 30 - 79 and pay only $2.37 each
  • Buy 80 or above and pay only $2.00 each
SKU:
JASEPCB56
UPC:
811681033054
Condition:
New

Contact Geometry Bifurcated
Contact Material Brass
Contact Plating Gold
Contact Resistance 10 mOhm
Current 3 A
Humidity 5 to 95 % R.H.
Insulation Resistance 100 GOhm
Insulator Polyphenylene
Pins 56
Temperature Rated 120 C
Withstanding Voltage 1600 V (1 Minute)
JAMMA 56 Pin Arcade Card Edge Connector Socket, PCB Mount, 3.96mm / 0.156"

Product Overview

56-pin JAMMA Aracde Edge Connector


Edge connector for JAMMA boards, this is the 56-pin version.

Features 2 rows of 28 contacts, each contact is gold-plated brass, bifurcated for a more reliable signal path.

The terminals are PCB pins, meaning they're designed for soldering to a circuit board
