User Port Connector Kit
Edge connector and housing for the user port of commodore computers (such as PET and Commodore 64) as well as the IEEE-488 port of the PET CBM series computers.
The blue connector features 2 rows of 12 contacts (marked with numbers 1...12 and letters A...L), each contact is gold-plated brass, bifurcated for a more reliable signal path. The terminals have solder eyelets on the rear, for easy soldering of wires.
Also included are two polarizing keys (white inserts) that are placed between terminals to prevent the plug being inserted upside-down (or in the incorrect port on the PCB).
The black single-piece polyamide housing has a side entry hole for the cable. A clamp holds the cable in place to prevent stress on the solder joints.
The blue connector is held to the housing by two screws that fit into the pre-drilled holes of the housing.
Edge connector and housing for the user port of commodore computers (such as PET and Commodore 64) as well as the IEEE-488 port of the PET CBM series computers.
The blue connector features 2 rows of 12 contacts (marked with numbers 1...12 and letters A...L), each contact is gold-plated brass, bifurcated for a more reliable signal path. The terminals have solder eyelets on the rear, for easy soldering of wires.
Also included are two polarizing keys (white inserts) that are placed between terminals to prevent the plug being inserted upside-down (or in the incorrect port on the PCB).
The black single-piece polyamide housing has a side entry hole for the cable. A clamp holds the cable in place to prevent stress on the solder joints.
The blue connector is held to the housing by two screws that fit into the pre-drilled holes of the housing.
